Honeywell Metrologic MK3580 Quantum T Omnidirectional Single Line Laser BarCode Scanner

Honeywell MK3580 Quantum T Omnidirectional Single Line BarCode Scanner

The Honeywell Metrologic MK3580 QuantumT is a compact, versatile, and accurate omnidirectional/ single line bar code scanner. It's rugged, durable and reliable, making it ideal for a variety of retail presentation scanning applications including convenience stores, liquor stores and pharmacies.

The Honeywell Metrologic MK3580 provides retailers with industry leading omnidirectional scan performance and optional single-line scanning in a convenient size. The small footprint and numerous stand options for MS3580 minimize required counter space, increasing available room for merchandise and advertisement displays.

Ideal for presentation scanning in moderate volume retail environments such as convenience stores, liquor stores and pharmacies, end users can individually customize the scan pattern and operate the scanner in either a hand-held or hands-free fashion. In addition, its rugged, rubber housing provides the necessary protection against daily operational use. QuantumT, with an industry-leading 1,650 scans/second, provides aggressive first-pass scanning, reducing the time it takes to scan products, increasing customer satisfaction and employee efficiency. The single-line scan feature, enabled by the push of a button, saves time and reduces unwanted scans on menu-style codes by providing targeted scanning through Metrologic’s patented Codegate® technology. Hand-held operation ensures easy scanning of larger, bulkier products that cannot be easily presented to stationary scanners. QuantumT can be positioned at the user’s convenience; mounted to a wall or countertop, atop one of four optional stands, or free standing for easy hand-held use. Other key features include Metrologic’s patented IR activation mode, userreplaceable Powerlink cables and Flash memory. QuantumT is an integral part of Metrologic’s new line of omnidirectional bar code scanners that are “Powered by Metrologic’s QuantumETM Scan Engine.”

QuantumT TM provides retailers with industryleading omnidirectional scan performance and optional single-line scanning in a convenient size. The small footprint and numerous stand options for QuantumT minimize required counter space, increasing available room for merchandise and advertisement displays.

FS USB is power plus USB for IBM SurePOS or NCR terminals.
LS USB is low speed USB for IBM PC/Clones.

Honeywell Metrologic MS3580 QuantumT® Quick Specs

Depth of Scan Field: (programmable) 25 mm - 280 mm (1” - 11”) for 0.33 mm (13 mil) bar code at default setting

Width of Field: 30 mm (1.2”) @ 25 mm (1"); 150 mm (5.9”) @ 280 mm (11”)

Scan Speed: Omnidirectional: 1650 scan lines/sec; Raster: 320 scan lines/sec; Single-line: 80 scan lines/sec

Minimum Bar Width: 0.127 mm (5 mil)

System Interfaces: RS232, Light Pen Emulation, Keyboard Wedge, Stand Alone Keyboard, IBM 468x/469X, USB , Laser Emulation, OCIA Light Source: Visible Laser Diode 650 nm

Honeywell Metrologic MS3580 QuantumT® Features & Benefits

Omnidirectional/Single-line modeAlternate between 20 scan lines for omnidirectional scanning and a single scan line for menu scanning

Sleep Mode with IR wake-up Multiple sleep modes reduce power consumption, extending life and lowering cost of operation

Small footprintKeeps valuable counter space clear

Optional standsCustomize the height of the scanner for unique applications

OPOS and JPOS system compatible QuantumT is compatible with systems running the popular industry standards

Warranty Metrologic QuantumT provides industry leading 3 year warranty.

Honeywell Metrologic MS3580 QuantumT® is available in 4 pole types

3" Pole with square base, non-weighted46-00288

6" Pole with square base, non-weighted46-00289

3" Pole with oval base, weighted46-00291

6" Pole with oval base, weighted46-00292

Honeywell Metrologic MS3580 QuantumT® Data Sheet(.pdf 284KB)
Honeywell Metrologic MS3580 QuantumT® Metro Select Config Guide (.pdf 2.3MB)
Honeywell Metrologic MS3580 QuantumT® Installation & User Guide (.pdf 5.3MB)

---

***Order Online the Honeywell Metrologic MS3580 QuantumT USB HID Kit. Includes MS3580-38 USB-HID Scanner (No power supply needed), Low Speed (Use with PC/Clone), Weighted rubber boot/stand, USB Cable (P/N 54-54235-N-3), Color: Black. Includes Installation Man
ual/CD.***
