Honeywell Intermec EasyCoder PD41 & PD42 Industrial Printer
Intermec EasyCoder® PD41 is a dependable and versatile printer suitable for medium duty applications in manufacturing, transportation and warehousing environments. With all-metal chassis and covers, proven printing mechanics and powerful electronics, it provides the sturdiness and performance your business depends on.
The EasyCoder PD41 can print demanding crisp variable-data labels continuously at 150 mm/s (6 ips), thereby outperforming all other printers in its class. It takes industry-standard 200-mm (8-in) rolls of labels and 450 m (18 000 in) of ribbon, reducing downtime for loading media to a minimum. The printer accepts a wide range of paper types in different thicknesses, as well as both ink-in and ink-out ribbon.
In addition the EasyCoder PD41 offers many Smart Printing™ features normally found only in high-performance printers Multi-language capability and Intermec Ready-to-Work™ indicator are standard – all at an affordable and competitive price. Networking is an increasingly important user requirement but still a rare feature in this printer class. The EasyCoder PD41 offers EasyLAN™ high-speed, multi-channel Ethernet as a standard choice.
PrintSet™, a PC-based setup tool, makes installation and setup of the EasyCoder PD41 intuitive and easy. The one-button interface makes the printer easy to operate and well protected against unintentional changes of the setup. An open and accessible design makes media loading quick and easy, and the printhead can easily be replaced without using any tools.
The ability to use any Intermec printer language and emulate other printer protocols makes the EasyCoder PD41 both fully compatible with other Intermec equipment and a cost-effective 'drop-in' printer replacement in almost any non-Intermec firmware environment. Featuring full programmability (using Fingerprint), the EasyCoder PD41 can change with the application. There's no need to replace the printer when you upgrade your firmware environment–the printer will adapt.Intermec EasyCoder PD41 Features & Benefits
Best performance in its class – prints at 6 ips continuously
Best print quality in its class – crisp and clear labels even at full printing speed
Metal chassis and covers, proven mechanics
User friendly design, simple one-button operation
Many features at an affordable price
Multi-lingual capability, adapts to host environment changes
Unicode printing support – wide selection of fonts, including many non-Latin
Temperature: +5°- 40°C (+40°- 104°F)
Humidity: 20-85% non-condensing free air
• Serial RS-232
• USB v. 2.0 full speed
• Parallel or EasyLAN Ethernet (depending on configuration)
• Parallel IEEE 1284 or
• EasyLAN integrated Ethernet: RJ-45
connector for 10BaseT or 100baseTX
TCP/IP-suite (TCP,UDP, ICMP, IGMP, etc.), LPR/LPD, FTP, BOOTP, DHCP,
HTTP, SNMP, SMTP, SNMP-MIB II supported (over UDP/IP), private enterprise MIB included
Standard: 4MB Flash memory 8MB SDRAM (1 Compact Flash slot)
Optional: Up to1GB CompactFlash (type 1) memory
Length: 453 mm (17.8 in)
Height: 273 mm (10.8 in)
Width: 270 mm (10.6 in)
Weight: 13 kg (28.7 lbs)
Fonts & Emulation
Language Emulation: IPL, Fingerprint, ZPL, DPL, EPL, XML
Voltage Range: 100-240 VAC ±10% auto switch
Frequency Range: 45-65 Hz
104 mm (4.09 in) at 203 dpi
105.7 mm (4.16 in) at 300 dpi
1520 mm (59.8 in) at 203 dpi
1028 mm (40.5 in) at 300 dpi
Supported Bar Code Symbologies:
Codabar, Code 11, Code 39, Code 39 full ASCII, Code 39 w. checksum, Code 93,
Code 128, Code 128 Subset A-C, DUN-14/16, EAN-8, EAN-13, EAN-128, EAN-128
Subset A-C, Five-Character Supplemental Code, Industrial 2 of 5, Industrial
2 of 5 w. checksum, Interleaved 2 of 5, Interleaved 2 of 5 w. checksum, Interleaved
2 of 5 A, Matrix 2 of 5, Postnet, Straight 2 of 5, Two-Character Supplemental
Code, UCC-128 Serial Shipping Container Code, UPC-5 digits Add-On Code, UPC-A, UPC-D1
to D5, UPC-E, UPC Shipping Container Code, RSS, Planrt, Plessey
Code 16K, Code 49, Data Matrix, MaxiCode, MSI(modified Plessey), PDF 417,
QR Code, MicroPDF417, EAN.UCC Composite
On Site Plans (Call for pricing)
Intermec Medallion On Site Service Contract plans provide a variety of commitment and coverage levels of industry-leading repair service.
Intermec Medallion Depot Service Contract plans provide a variety of commitment and coverage levels of industry-leading repair service.
SiteCare visits help prevent small problems from growing into large ones, and allow customer staff to focus on more business-critical daily activities.
Intermec EasyCoder PD41 Data Sheet (.pdf 132KB)
Intermec Direct Thermal Labels
Intermec Thermal Transfer Labels
Intermec Thermal Transfer Ribbons(Wax, Wax/Resin, Resin)
***Intermec Label & Ribbon Order Form (.html 14KB)***
*Included in Printer Box:
Power cord, USB Cable; Ribbon Core; User QuickStart Guide; Companion CD w/Windows Drivers, LabelShop software & Manuals.
Order Online the Honeywell Intermec EasyCoder PD41BJ1000002020 Direct Thermal & Thermal Transfer Printer PD41B, 203 dpi, US/EU Cord, Ethernet Interface and Label Taken Sensor .
